-Port isolation, effectively shielding broadcast storms
-Automatic loop detection function
-All ports support full-/half-duplex working mode
-Support MAC address self-learning
-Plug and play, no management required
|
Product model |
NS124V |
| Standard protocol | IEEE 802.3 10Base-T, IEEE 802.3u 100Base-TX, IEEE 802.3x |
| Network medium |
10Base-T: CAT3 or above UTP 100Base-TX: CAT5 or above UTP |
| Port | 24*10/100M RJ45 LAN port |
| Backplane bandwidth |
4.8Gbps |
| MAC address table | 8K |
| Size | 200*125*45MM (L*W*H) |
| LED display | 10/100Mbps（LINK/ACT）、Power |
| Forwarding mode | Store and forward |
| Access method | CSMA/CD |
| VLAN |
Fixed VLAN |
| Power | DC 12V/1A |
| Working environment |
Operating temperature: 0°C ~ 40°C Storage temperature: -20°C ~ 70°C Operating humidity: 10% ~ 90%, RH non-condensing Storage humidity: 5% ~ 90%, RH non-condensing |
